| Part n. | Product Name | Retail price (€ ea.) | Voltage (V) | Consumption (A) | Fuse (A) | Flow rate (gpm) | Self-priming (ft) | Pressure (psi) | O-Ring | Seal | Hz | Ports (BSPP) | Hose (in) | IP Protection | Motor power (W) | Weight (lb) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 16440312 | UP10-XA | Login | 12 | 11 | 25 | 4.8 | 9.8 | 72.5 | FKM | FKM | DC | 3/8" | 1/2 | 67 | 360 | 9 |
| 16440313 | UP10-XA | Login | 24 | 5 | 20 | 4.8 | 9.8 | 72.5 | FKM | FKM | DC | 3/8" | 1/2 | 67 | 360 | 9 |
| 16440612 | UP10-XA | Login | 12 | 11 | 25 | 4.8 | 9.8 | 72.5 | EPDM | EPDM | DC | 3/8" | 1/2 | 67 | 360 | 9 |
| 16440613 | UP10-XA | Login | 24 | 5 | 20 | 4.8 | 9.8 | 72.5 | EPDM | EPDM | DC | 3/8" | 1/2 | 67 | 360 | 9 |
